MPC 27×27 Series

Part No. Chipset ( mm ) Heat Sink ( mm ) Air Velocity / Rth ( oC/W )
Size Length width height Natural

Convection

 200 lfm 400 lfm 600 lfm
MPC27-12 27 27 27 12 12.27 4.28 2.76 2.23
MPC27-15 27 27 27 15 11.85 4.02 2.56 2.03
MPC27-18 27 27 27 18 11.53 3.78 2.35 1.85
MPC27-21 27 27 27 21 11.16 3.53 2.19 1.71
MPC27-23 27 27 27 23 10.75 3.31 2.00 1.57
MPC27-28 27 27 27 28 9.93 3.01 1.83 1.44
MPC27-33 27 27 27 33 9.43 2.79 1.70 1.34
